High Resistance to Hydrochloric Acid, Sulfuric Acid, Pitting, and Crevice Corrosion
Hastelloy HYBRID-BC1 (UNS N10362) alloy possesses much higher resistance to hydrochloric and sulfuric acids than the nickel-chromium-molybdenum (C-type) alloys, and can tolerate the presence of oxidizing species. The alloy also exhibits extremely high resistance to pitting and crevice corrosion.
Hastelloy HYBRID-BC1 Applications
Hastelloy HYBRID-BC1 alloy is suitable for the following applications in the chemical processing, pharmaceutical, agricultural, food, petrochemical, and power industries
- Reaction vessels
- Heat exchangers
- Valves
- Pumps
- Piping
- Storage tanks
The alloy is suitable for use at temperatures up to approximately 427°C (800°F). HYBRID-BC1 alloy excels in reducing acids and acid mixtures (with or without halides) open to oxygen and other oxidizing residuals/contaminants.
Hastelloy HYBRID-BC1 Chemical Compositions
| Weight % |
| Nickel | Balance |
| Cobalt | 1 max. |
| Molybdenum | 22 |
| Chromium | 15 |
| Iron | 2 max. |
| Aluminum | 0.5 max |
| Manganese | 0.25 |
| Silicon | 0.08 max. |
| Carbon | 0.01 max. |
Hastelloy HYBRID-BC1 Physical Properties
| Condition | Test Temperature | Impact Strength |
| - | °F | °C | ft-lbf | J |
| Solution Annealed | RT | RT | 360 | 488 |
| Solution Annealed | -320 | -196 | 376 | 510 |
| Annealed + Age Hardened* | RT | RT | >246 | >358 |
| Annealed + Age Hardened* | -320 | -196 | 256 | 347
|
